Hyper Tool Gundrilling Data Questionnaire


Company

Manufacturing Contact

Phone

Email


Purchasing Contact

Phone

Email


Integrated Supplier

Phone

Email


Address

City

State

Country


Hole Data:

Hole Diameter

Tolerance

Surface Finish

Horizontal or Vertical Application?
   Horizontal Vertical
Hole Depth Required

Hole Is:
  Blind Through Interrupted
Diameter of largest Cross hole
   Holes are same centerline as this hole.*
    *if not on the same centerline attach part print
Maximum Run out Allowable


Work piece Material Data:

Type of part being drilled

Work piece Material


Hardness(Specify Units)


Work piece Is:

Describe Chips:
Average Length

Width
Thickness
Color
Drill Data:

Your Drill Part Number

What Rotates?
  Drill Work piece Both (counter-rotation)
Drill Diameter

Number of Flutes

Shank (Tube) Diameter

V-flute Central Angle
   deg.
Drill Point Angles: Outer Angle
   deg. Inner Angle deg.
Cutting edge clearance angle
   deg
Point Location with Respect to OD

Back taper per inch (BTPI)

Drill Overall Length
   Minimum required Flute Lenth
Driver:
   Diameter OD Tolerance Length
    Threaded backend? Thread pitch O-ring
    Clamping
Tip Configuration
  Round Hole Twin Hole Kidney Hole
Drill is made with
  Solid Carbide Tip Brazed Carbide Inserts Detachable Tip
Carbide Grade
     Coating
Cutting Speed
   RPM SFPM
Cutting Feed
     IPR IPM
Number of Holes per regrind
   Criteria for re sharpening
Describe wear type and location(s)

Regrind Method
   Brand of Fixture Type of Point
Gundrilling Machine Data:

Machine is Made by Type

Year   Number of Spindles

What is the condition of your machine?
NEW
GOOD
OLD
HARD TO SAY		 Does it have
Variable Speed
Variable Feed
CNC Controller
Drill Protection Device

Have You Ever Checked Spindle to Bushing Alignment of the Machine:  Yes No

What was the measured value of the misalignment?  Over

Maximum Spindle RPM Available:  Infinitely variable?

If not Infinitely variable, list what RPM rates are available
Available Feed Range:  Infinitely variable?

If not Infinitely variable, list what feed rates are available
Type of adapter (Chuck Where a Gundrill is Installed)
Drill Guides:
Measure to the nearest ½ inch.
A
Distance between front of bushing and part being drilled
B
Width of Chip Box.
C
Width of Mid-span Support
D
Distance from Front of Spindle to Front of Gundrill Bushing.

  Starting (pilot) hole made with the drill having included point angle deg.
  Starting Bushing,Bushing ID and Tolerance
Bushing OD

Bushing Length

Bushing Type (if special attach sketch)

Bushing Material

Do you use Gizmos?

Other type of Whip guides?

Number of mid -span supports used



Coolant Data:

Please, check suitable boxes below

What is the type of coolant in use?
Oil based
Oil based with special additives
Water based (soluble) with less than 10% concentration

Water based (soluble) with more than10% concentration

Where is coolant pressure gage installed?
Before Coolant Filter(s)
After Coolant Filter(s)
I Have Two Pressure Gages

Don't know


Coolant Brand Coolant Manufacturer
Maximum available Coolant Pump Pressure Maximum possible Flow Rate

Coolant pump is Fixed Displacement Variable Displacement
Pressure (psi) Flow rate Temperature(°F)
Coolant Filtration (Maximum Size of Particles Found in Coolant)  Microns
EP additives present:  %Chlorine %Sulfer (Consult MSDS sheet)


Please describe any current problems and/or desired improvements sought
 Form is Filled Out by Date
